| Place of Origin: | China |
|---|---|
| Brand Name: | Safegas |
| Certification: | ATEX, ISO9001, CE, CNEX |
| Model Number: | YT-1200H-S |
| Minimum Order Quantity: | 1pcs |
| Price: | Negotiable |
| Packaging Details: | Color box. 30*25*13cm |
| Delivery Time: | 1 working days |
| Payment Terms: | Credit Card, Western Union, T/T |
| Supply Ability: | 1000 pieces/week |
| Detected Gas: | O2 CO2 | Measure Range: | 0-30%vol, 0-2000ppm, 0-5000ppm |
|---|---|---|---|
| Sampling Method: | Diffusion | Alarm Type: | Sound, Light |
| Resolution: | 0.01%vol, 1ppm | Packing: | Color Box |
| Material: | PC + ABS | USB Port: | Mini USB Port |
| Warranty: | 12 Months | Calibration Certification: | Yes |
| Weight: | 240g | Size: | 131*83*35mm |
| Working Temperature: | -20℃~50℃ | ||
| High Light: | Portable CO2 Gas Detector,Back Clip Portable Gas Detector,Light Weight O2 Gas Detector |
||
Portable O2 CO2 gas detector small size light weight with back clip
Product information
Specifications
| Gas Detected | O2 CO2 | ||
| Detection principle | Electrochemistry, Infrared | ||
| Sampling Method | Diffusion | ||
|
Measure Range |
|||
| Resolution | 0.01%vol, 1ppm | ||
| Precision | ≤± 5% F.S | ||
| Signal Output | High-speed data transmission by USB, available for data downloading and printing (optional function) |
||
| Charging Time |
4~6h |
Working Time | 14h |
|
Battery |
3.7V |
Capacity |
2300mAh |
| Zero shift | ≤±1%(F.S/year) | Display | LCD dot matrix display |
| Operating language | English | Gas unit | Units are switchable |
| Temperature | -20℃~50℃ | Humidity | 0-95%RH |
| Explosion-Proof | II 2G Ex ia IIC T4 Ga IP66 | Degree of protection | IP66 |
| Alarm mode | Sound, light, vibration |
Housing Material |
ABS+ leather case |
| Dimensions | 131*83*35mm | Weight |
240g |
Characteristics
1. Employing original imported first-class brand sensor.
2. (optional) High speed data transmission by USB, which can download and print data.
3. LCD dot matrix display, the gas type, unit, concentration,
4. Local time can be showed on the screen.
5. Support Chinese and English operation, easy to shift.
6. The gas concentration unit PPM and mg/m3 can be shifted quickly. Built-in micro sampling pump, 10 grades of suction are available.
7. Explosion-proof certification, explosion-proof grade: II 2G Ex ia IIC T4 Ga IP66.
8. Monitor the specified gas concentration in environment and enclosed space and alarm.
9. With Self-calibration and zero calibration functions, makes the detection more accurate and reliable.
10. One press to restore factory setting, free from the bother of mis-operation With temperature and pressure compensation, this is able to realize gas concentration compensation under conditions of different temperatures or pressures.
11. Two-stage alarm with sound and light, alarm point is settable.
12. Rechargeable lithium polymer battery of large capacity.
13. Special engineering plastics housing of high intensity, anti-skipping,
14. Water-proof, dust-proof, explosion-proof.
Factory information
FAQ
Q1: Are you factory or trade company?
A1: We are factory.
Q2: What about the payment method?
A2: Credit card, T/T, Western Union are available
Q3: Does your company accept customization?
A3: We do customizing service for customers.
Q4: What about the Shipment?
A4: We’ll choose proper transportation mode based on the weight of goods, usually arrange shipment byair express such as DHL,FEDEX,TNT or UPS.
Q5: What about after-sale service?
A5: 12 months warranty or 24 months warranty for all kinds of products.
Q6: How about the Calibration?
A6: Before send out, we will calibrate each pieces well with standard gas.
Q7: What certifications do you have?
A7: ATEX CE ISO9001-2015.
