MiniMeta Portable Single Gas Detector
Product Overview
MiniMeta is a cost-effective portable single gas detector that meets global hazardous area safety standards. It is powered by a replaceable 3.6V non-rechargeable dry battery, delivering 2 years of standby without extra charging or calibration work. The sensor and battery can be swapped independently to extend service life. This SO2 version adopts an imported electrochemical sensor, with a measuring range of 0–100ppm, 0.01ppm resolution, ≤±2–5%FS accuracy and 15–30s T90 response time. It provides adjustable multi-type alarms and complete real-time data display. Matching DKM docking station and DKS software are available for batch maintenance and data archiving.
Product Pictures
The Hazards & Detection Significance of Sulfur Dioxide
Sulfur dioxide is a pungent toxic air pollutant produced by fuel combustion and industrial manufacturing, which causes varying degrees of respiratory damage to human bodies under different concentrations, with 100ppm as the IDLH critical value.
Main SO2 Emission Sources
Combustion: coal power plants, refineries, ships Metallurgy: copper/zinc/lead smelters, cement plants Chemical: sulfuric acid & fertilizer factories Food: dried fruit fumigation, wine brewing Natural: volcanic vents, hot springs
Concentration Corresponding Health Risks
0.3–1ppm: odor and mild mucosal irritation 1–5ppm: coughing and weakened lung function 5–10ppm: severe bronchial irritation 10–50ppm: acute breathing difficulty ＞50ppm: permanent lung injury or death
Main Application Scenarios
Power plant flue gas inspection, petroleum refineries, non-ferrous smelters, pulp & paper mills, food fumigation workshops, urban environmental monitoring, chemical plants, marine vessels, mining and laboratory fume hoods.
Key Technical Specifications
|
Parameter
|
Value
|
|
Target Gas
|
Sulfur Dioxide (SO2); compatible with O2, H2S, CO and hundreds of other gases
|
|
Sensing Principle
|
Imported Electrochemical Sensor
|
|
Measuring Range
|
0 – 100 ppm
|
|
Resolution
|
0.01 ppm
|
|
Accuracy
|
≤ ±2–5% FS
|
|
T90 Response Time
|
15–30 seconds
|
|
Display Content
|
Gas type, concentration, unit, battery, TWA/STEL/MAX/MIN
|
|
Alarm Configuration
|
95dB buzzer, dual red LEDs, vibration; adjustable high/low alarm, STEL, TWA, low battery, calibration & bump test reminders
|
|
Power Supply
|
3.6V replaceable non-rechargeable dry battery
|
|
Standby Cycle
|
2 years (no charging or regular calibration required)
|
|
Optional Functions
|
Event & data logging, automatic power-on self-test
|
|
Safety Standard
|
Ex ia IIC T4 Ga explosion-proof, IP68 waterproof & dustproof
|
|
Compliance Standards
|
GB 12358-2006, GB 3836 series, IEC 60079 series
|
|
Working Temp
|
-20°C ~ +55°C
|
|
Working Humidity
|
0–95% RH (non-condensing)
|
|
Air Pressure Range
|
86–106 kPa
|
|
Dimension
|
90 * 60 * 33 mm
|
|
Net Weight (with clip)
|
125 g
|
Main Features
- Global safety certification: IECEx, ATEX, EMC & Ex ia IIC T4 Ga, applicable to Zone 0/1/2 hazardous zones
- IP68 fully sealed housing, resistant to dust splashes and temporary soaking
- 2-year ultra-long standby, powered by replaceable 3.6V dry battery without frequent maintenance
- Modular sensor and battery design, effectively lowering long-term use costs
- Triple safety alarms including sound, light and vibration, all alarm thresholds editable on site
- Complete real-time data screen covering concentration and cumulative exposure indicators
- Automatic power-on self-test to check sensor and circuit status for higher safety
- Two optional management tools: DKM docking station and DKS software for calibration and data export
- Mini lightweight body with matching back clip for comfortable all-shift wearing
Typical Applications for SO₂ Detection
- Power & waste incineration plants: Monitor flue gas and desulfurization system efficiency
- Petroleum refineries: Leak detection for sulfur recovery units and pipelines
- Metal smelters: Personal protection in ore roasting and conversion workshops
- Pulp & paper factories: Gas monitoring in pulping and recovery boiler areas
- Food processing: Safety protection for fruit sulfur fumigation and wine production
Standard Package
- 1 * MiniMeta SO2 single gas detector
- 1 * Calibration cap
- 1 * User manual
- 1 * Conformity certificate & warranty card
Manufacturer Profile
Shenzhen YuanTe Technology Co., Ltd. (Safegas) – founded in 2010. Over 16 years in gas detection R&D, manufacturing, and sales. Serves oil & gas, chemicals, environmental protection, electronics, municipal engineering, agriculture, and household appliances.
Certifications: IECEx, ATEX, EMC, ISO9001, ISO45001
Annual output: >80,000 units
Delivery: 5–7 working days typical
Support: 24/7 after-sales service
