Safeguarding Lives Ambient Air Analyzer Pump Suction With 18 Gases Detection

Basic Information
Place of Origin: China
Brand Name: Safegas
Certification: ATEX/CE
Model Number: SKY8000
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Aluminum Suitcase Package
Delivery Time: 5 - 7 working days
Payment Terms: Western Union, T/T, Visa, Master Card
Supply Ability: 1000 piece/ month
Detail Information
Detecting Gas: Maximum Detection Of 18 Gases (Customized) Sensor Type: Customized
Measure Range: Customized Resolution: Customized
Application: Petrochemical, Power Plant, Building, Mine, Metallurgical Coking, Pharmaceutical Sampling Method: Pump-suction
Display: Formula, Gas Concentration Data, Measurement Trend Curve, Gas Curve, Battery, Time, Temperature, Humidity, Pressure (optional), Pump Condition, Wireless Status, Printer Status, Screen Shot Status Alarm: Red LED, Buzzer, Alarm Status On The Display, Fault Alarm, Pump Abnormal Alarm And Low Battery Alarm
Language: Chinese/English Warranty: 12 Months
High Light:

Pump Suction Ambient Air Analyzer

,

Safeguarding Lives Ambient Air Analyzer


Product Description

Safeguarding Lives Air Quality Gas Analyzer with Detection of Up to 18 Gases to Prevent Gas Leaks



Company Profile



Shenzhen Yuante Technology Co., Ltd., a leading high-tech enterprise, is at the forefront of gas detection and analysis technology. Through independent research and development, strategic collaborations, and continuous learning from advanced global technologies, we have not only maintained our leadership in domestic products and technology but also achieved parallel growth with international counterparts. We invite distribution agents, OEMs, and ODMs to join us in our journey towards a safer future. With Yuante, let’s collaborate to build a brighter tomorrow.



Product Overview



The SKY8000 series gas analyzer is a rapid and proficient data collector, excelling in the collection and analysis of gas concentration components in intricate environments such as scientific research institutions and universities. With the capability to simultaneously detect up to 18 types of gases, the SKY8000 amalgamates various detection principles, including electrochemistry, catalysis, thermal conductivity, infrared, photoionization, and ultraviolet. Our focus is on guaranteeing precision and elevating the user experience in gas detection.


Product Advantage



  • This device, equipped with a Mini-USB charging interface, guarantees easy charging.
  • With the ability to simultaneously detect up to 18 different gases, it meets a wide range of detection requirements.
  • The device features a top-of-the-line sensor from a prestigious UK brand and an integrated micro sampling pump, ensuring rapid response and high precision.
  • Its distinctive structural design incorporates aviation-grade wear-resistant materials, making it adaptable to various industrial environments.
  • A 3.5-inch high-definition color screen is included, offering a clear and smart display of interchangeable gas concentration data and real-time curves.
  • It also includes an independent SD memory card for accessing and deleting historical test data, with customizable storage capacity.
  • It can be outfitted with either an integrated printer or an external Bluetooth printer for on-the-go printing capabilities (optional).





Safeguarding Lives Ambient Air Analyzer Pump Suction With 18 Gases Detection 0

Specification



Sensors
Various principle sensors can be combined in any number , up to 18 sensors; Combustible: catalytic combustion principle orinfrared principle;
oxygen: electrochemical principle or zirconia principle;
toxic: electrochemical principle;
CO2: infraredprinciple;
VOC: PID photo ion principle;
CH4: catalytic combustion principle or infrared principle;
He: thermal conductivity Principle,
temperature and humidity sensors, pressure sensors (optional) (other principles of the sensor can be customized)
Measure range
0~1,10,100,1000,5000,50000,100000 PPM;0-100mg/L,200mg/L;
0-100%LEL;0-10%,20%,50%,99.999%,100%Vol(Measure range is optional and customerized)
Resolution
0.001 PPM(0-1 PPM);0.01 PPM or 0.001 PPM(0~10 PPM);
0.1 PPM or 0.01 PPM(0~100 PPM);1 PPM or 0.1 PPM(0~1000 PPM);
1 PPM(0~1000 PPM);0.01mg/L(0~200%mg/L);0.1%LEL(0-100%LEL);0.01%(0-100%VOL)

Display
Formula, gas concentration data, measurement trend curve, gas curve, battery, time, temperature, humidity, pressure (optional),
pump condition, wireless status, printer status, screen shot status
Alarm
Buzzer, red LED and alarm status on the display, fault alarm, pump abnormal alarm, low battery alarm
Data storage
Independent SD memory card, Max.32G, measurement data can be record automatically, customizable record time interval.
Data transmission and download
RS232,RS485 singnal output, USB interface data transmission, with the upper computer software, can download storage, analyze and
print data
Print function(Optional)
Optional with internal portable printer or external bluetooth printer
Print content(Optional)
Text, graphics, one-dimensional code, two-dimensional code, curves, characters, etc.

Charger
Standard Mini-USB charging port. With 13V/2A special charger (built-in printer) or 5V/2A universal charger (external printer )
Language
Chinese/English
Wireless network (optional)
Bluetooth, Zigbee
Network frequency
2.4G high frequency.
wireless transmission distance
Bluetooth is less than 10m, and the ZigBee outdoor single point is less than 500m.
