Mini Handheld Single H2S Hydrogen Sulfide Industrial Gas Monitor ISO9001

Basic Information
Place of Origin: China
Brand Name: YuanTe
Certification: CNEX, ISO9001, CE
Model Number: YT-1200H-S-H2S
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Color paper box
Delivery Time: 3-5 working days
Payment Terms: Western Union, T/T
Supply Ability: 1000 pieces/week
Detail Information
Detected Gas: H2S Measure Range: 0-50ppm、100ppm、200ppm、0-1000ppm、2000ppm
Ampling Method: Diffusion Alarm Type: Sound, Light, Vibration
Resolution: 1ppm, 0.01pm, 0.001ppm Packing: Color Paper Box
High Light:

industrial gas monitors

,

gas measuring device


Product Description



Mini Handheld Single H2S Hydrogen Sulfide Industrial Gas Monitor ISO9001



Hydrogen sulphide (H2S) is a highly poisonous gas common in most mines. Harmful concentrations are often found in gypsum mines, tunnel digging, caissons, and can be mixed with natural gas. Because it is heavier than air it tends to accumulate at the bottom of poorly ventilated spaces like mines. Although very pungent at first (rotten eggs/flatulence), it quickly deadens the sense of smell, so potential victims may be unaware of its presence until it is too late. Yuante’s can give you different options of H2S detector and analyzers.



Specifications



Gas Detected H2S
Detection principle Electrochemisty
Sampling Method Diffusion
Measure Range 0-50ppm,100ppm,200ppm,0-1000ppm,2000ppm
Resolution 1ppm, 0.01pm, 0.001ppm
Precision ≤± 3% F.S.
Signal Output High-speed data transmission by USB, available for data downloading and
printing (optional function)
Charging Time

4~6h

Working Time 14h

Battery

3.7V

Capacity

2300mAh

Zero shift ≤±1%(F.S/year) Display LCD dot matrix display
Operating language Chinese/English Gas unit Units are switchable
Temperature -20℃~50℃ Humidity 0-95%RH
Explosion-Proof ExiaⅡCT3 Degree of protection IP65
Alarm mode Sound, light, vibration

Housing Material

ABS+ leather case
Dimensions 131*83*35mm Weight

240g





Characteristics



Employ original imported high-precision sensor.

Four random gas sensors can be combined freely.

LCD dot matrix display, support Chinese and English operation.

The gas concentration unit PPM and mg/m3 can be shifted quickly.

The battery and voltage can be checked by one press.

One press to restore factory settings.

Ultra-high buzzer alarm sound, alarm with sound, light and vibration at the same time.

Can record 100 sets alarm data, alarm record can be checked on the device.

Data storage function, can record 100 thousand set data, historical data can be viewed on the device (optional function).

Rechargeable lithium polymer battery of large capacity, which ensure the device to work

continuously for a long time.

Strong and upscale alligator clip, convenient to take along during operation.

Special engineering plastics housing of high intensity, strong and durable, exquisite and comfortable in touching.
