Analyzer Portable Flue Gas Analyzer H2S Detection Accurate And Stable Performance

Basic Information
Place of Origin: China
Brand Name: YuanTe
Certification: CNEX,ISO9001,CE
Model Number: SKY8000-H2S
Minimum Order Quantity: 1 piece
Price: Negotiable
Packaging Details: Aluminum Suitcase
Delivery Time: 3-5 working days
Payment Terms: Western Union, T/T
Supply Ability: 100 pieces/week
Detail Information
Detected Gas: H2S Measure Range: 0-5000ppm, 0-1000ppm, 0-2000ppm
Sampling Method: Pumping Suction Alarm Type: Sound, Light, Vibration
Size: 260*230*120mm Weight: 3700g
Charging Method: Power Adapter, USB Cable Packing: Corrosion Resistant Suitcase
Highlight:

gas monitor detector

,

exhaust gas leak detector


Product Description



Analyzer Portable Flue Gas Analyzer H2S Detection Accurate and Stable Factory Price



SKY8000 series gas analyzer is a data collector which can quickly acquire and analyze gas concentration components in scientific research, university and complex working environment.

SKY8000 gas analyzer can detect up to 18 gases simultaneously. It can integrate electrochemistry, catalysis, thermal conductivity, infrared, light ion, ultraviolet and other detection principles, focusing on the accuracy of gas detection and user experience.



Specification

Sensors Professional Flue H2S Sensor
Measure range 0-5000ppm, 0-1000ppm, 0-2000ppm (Measure range is optional and customized)
Resolution 1ppm

Display
Formula, gas concentration data, measurement trend curve, gas curve, battery, time, temperature, humidity, pressure (optional), pump condition, wireless status, printer status, screen shot status
Alarm Buzzer, red LED and alarm status on the display, fault alarm, pump abnormal alarm, low battery alarm
Data storage Independent SD memory card, Max.32G, measurement data can be record automatically, customizable record time interval.
Data transmission and download RS232,RS485 signal output, USB interface data transmission, with the upper computer software, can download storage, analyze and print data
Print function(Optional) Optional with internal portable printer or external Bluetooth printer
Print content(Optional) Text, graphics, one-dimensional code, two-dimensional code, curves, characters, etc.

Charger
Standard Mini-USB charging port. With 13V/2A special charger (built-in printer) or 5V/2A universal charger (external printer )
Language Chinese/English
Wireless network (optional) Bluetooth, Zigbee
Network frequency  2.4G high frequency.
wireless transmission distance Bluetooth is less than 10m, and the ZigBee outdoor single point is less than 500m.




Accurate and reliable
- Using world top brand sensors, the test results are more reliable and can be certified by third party authorities
- Multiple industrial pump gas sampling, ten grades of pumping flow rate for selection.
- Gas detection flow can be customized according to different testing environments. Each module is equipped with multi-layer filtering device, which can filter oil, water, dust and other impurities efficiently.

Multi-display mode
- Single curve, multi-curve, data and other gas concentration display mode are switchable
- Various gas concentration units can be shifted freely

Comprehensive functions
- Modular internal structure, supporting 1-18 gas detection requirements
- Simple and quick screenshot settings
- Monitor the temperature, humidity, pressure at the same time(Optional)
- Bluetooth, ZIGBEE, WIFI, GPRS and other wireless communication modes are selectable(Optional)
- Analyzer can be equipped with internal printer or external Bluetooth printer, to realize the mobile print function(Optional)
- High temperature, high humidity environment measurement(Optional)

Data logging
- Large capacity quick storage function, storage space can be customized
- An independent SD memory card, historical tested data can be viewed and deleted

Mobile recharging and long operation time
- High capacity of lithium polymer rechargeable battery, super long service life and standby time
- Mini-USB charging interface design with common data cable and mobile power can be charged anytime, anywhere

High quality material
- 3.5-inch hd LCD screen with resolution 320* 480, beautiful and useful menu interface
- Selected aviation wear-resisting material, suitable for various kind of industry environment

Application
- Confined space, research and high standard test environment,
- Complex environment of multiple gases
