| Place of Origin: | China |
|---|---|
| Brand Name: | YuanTe |
| Certification: | ISO9001,CE,CNEX,ATEX |
| Model Number: | SKY2000-O3 |
| Minimum Order Quantity: | 1 piece |
| Price: | Negotiable |
| Packaging Details: | Aluminum Suitcase package |
| Delivery Time: | 3-5 days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1000 pieces/Week |
| Detected Gas: | O3 Ozone | Measure Range: | 0-1,5,10,20,100ppm |
|---|---|---|---|
| Sampling Method: | Pumping Suction | Alarm Type: | Sound, Light, Vibration |
| Size: | 205*75*32mm | Weight: | 300g |
| Charging Method: | Power Adapter, USB Cable | Packing: | Aluminum Suitcase |
| High Light: | 0.001ppm Gas Analyzer,O3 Ozone Portable Tester |
||
0.001ppm High Resolution O3 Ozone Single Gas Detector For O3 Air Purifier
Description:
Ozone is kind of broad-spectrum fungicide, it can kill bacterial reproduction, germ, virus, fungus, and it can damage the botulinus toxin. Because ozone molecule is not stable, so it will not pollute the air and water after disinfection. So, most pharmaceutical factories,food factories,Ozone generate companyt use ozone for sterilization in recent years. YuanTe’s Ozone gas detector can help the customers to detect the leak and the sterilization process of ozone gas in hospital,house.
Specification
| Gas Detected | Ozone/O3 | ||
| Detection principle | Electrochemistry | ||
| Sampling Method | Pumping suction, flow rate can up to 1L/min, ten grades of pumping suction for selection. | ||
| Measure Range | 0-1ppm,0-5ppm,0-10ppm,0-20ppm,0-50ppm,0-100ppm,0-200ppm,0-500ppm,0-1000ppm | ||
| Resolution | 0.001ppm,0.01ppm,0.1ppm,1ppm | ||
| Precision | ≤± 3% F.S. | ||
| Signal Output |
High-speed data transmission by USB, available for data downloading and printing (optional) |
||
| Response Time | ≤10S | Recovery Time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%(F.S/year) | Display | LCD dot matrix display |
| Operating language | Chinese/English | Gas unit | ppm, mg/m3 |
| Temperature | -20℃~50℃ | Humidity | 0-95%RH |
| Explosion-Proof | ExiaⅡCT4 | Degree of protection | IP66 |
| Alarm mode | Sound, light, vibration | Operating time | 12h |
| Dimensions | 205*75*32mm | Weight | 300g |
Functions:
1. LCD dot matrix display, the gas type, unit, concentration, local time, temperature and max measure value (optional) can be showed on the screen.
2. Support Chinese and English operation, easy to shift.
3. The gas concentration unit PPM and mg/m3 can be shifted quickly.
4. Explosion-proof certification, explosion-proof grade: ExiaⅡCT4.
5. Monitor the O3 ozone gas concentration in environment and enclosed space and alarm.
6. With Self-calibration and zero calibration functions, makes the detection more accurate and reliable.
7. One press to restore factory setting, free from the bother of mis-operation.
8. With temperature and pressure compensation, to realize gas concentration compensation under conditions of different temperatures or pressures.
9. Two stages alarm with sound and light, alarm point is settable.
10. Rechargeable lithium polymer battery of large capacity.
