VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof

Basic Information
Place of Origin: China
Brand Name: Safegas
Certification: IECEX, ATEX, ISO9001, CE, CNEX, SIL
Model Number: SKY3000
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Aluminum Suitcase
Delivery Time: 1 working days
Payment Terms: Credit Card, T/T
Supply Ability: 1000 pieces/week
Detail Information
Detected Gas: TVOC TVOCs VOC VOCs, Etc, Other Gases Are Customized Measure Range: 0-1, 0-10, 0-20, 0-50, 0-100, 0-200, 0-500, 0-1000, 0-2000, 0-5000, 0-10000, 0-15000ppm, Other Measure Ranges Are Customized
Sampling: Inner Suction Pump Alarm Model: Sound Light Vibration
Resolution: 0.001ppm, 0.01ppm, 0.1ppm, 1ppm, Other Resolutions Are According To Sensors. Sensors: Original Imported From UK, 10.6eV, Fast Response And High Precision
Wireless: (Optioanal)Bluetooth APP Protect Level: IP67
Response: T90≤10S Certifications: IECEX&ATEX, ISO9001, CE, SIL
High Light:

IP67 VOC Gas Analyzer

,

ATEX VOC Gas Analyzer

,

IP67 PID VOC Meter


Product Description

TVOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-proof



TVOC Gas Analyzer has obtained international IECEX, ATEX explosion-proof certification. And it is a high-performance portable gas detector that can detect multiple gases at the same time and has man down alarm function. The device has humanized operation functions such as one-key security detection, one-key storage, automatic image flipping, as well as the man down alarm function; With optional Bluetooth transmission function, allowing safety personnel to obtain real-time data and the alarm status. As it passed the antistatic test, and the protection level reaches IP67; With safer product design and the module designwhich makes the detection faster, and the compact ergonomic designmakes the device easy carrying.

Aplication for TVOC gas analzyer

Mainly used in petroleum chemical industry,metallurgy, mining, fire, gas, environmental protection, electric power, communication, papermaking, printing and dyeing, food reserves, city water supply, sewage treatment, food, brewing, research, education, national defense and other places.


Accessories & Configuration List

Standard Accessories

SKY3000
Aluminum suitcase
A charging adapter
User Manual
Qualification/Calibration certificate

Filter

Storage function(USB cable)



Optional Accessories

Probe

Tube

Bluetooth App


TVOC Gas Analyzer Specifications:

Sampling method

Pump suction

Gas type

TVOC TVOCs VOC VOCs etc, other gases are customized

Measure range

0-1, 0-10, 0-20, 0-50, 0-100, 0-200, 0-500, 0-1000, 0-2000, 0-5000, 0-10000, 0-15000ppm, other measure ranges are customized

Resolution

0.001ppm, 0.01ppm, 0.1ppm, 1ppm, other resolutions are according to sensors.

Response time

≤10 seconds

Precsiion

≤±1%F.S

Language

English(Other languages can be customized)

Automatically test and calibrate after power-on

Including reset, maximum value (MAX), minimum value (MIN), STEL, TWA value

Unit

PPM and mg/m³ can be switched

Disaply

monochrome graphics (160 x96) ,screen can be automatically flipped

Backlight

The backlight time can be manually set, and will be turned on automatically when an alarm is issued

Data record

Can store 100,000 sets data, the storage interval is adjustable from 5 to 3600 seconds, data can be exported

Alarm

95dB buzzer (@30cm), vibration alarm and flashing red LED and alarm status indication on the screen, alarm latched; diagnostic alarm and battery undervoltage alarm, pump block alarm; man down alarm, with early warning and optional real-time remote Bluetooth notification function

Battery

3.7V rechargeable lithium battery, battery capacity 2200mA

Working hours

More than 15 hours in continuous pumping mode

Charger

Travel charger with DC interface, charging time ≥ 4 hours

Explosion-proof grade

IECEX/ATEX(II IG Ex ia IIC T4
CNEX:Ex ia IIC T4 Ga

Certification
(EU regulations)

2004/108/EC(EMC)
1995/5/EC(Radio)
94/9/EC(ATEX)

Protection grade

IP67/IP68

Working temperature

-20ºC~+50ºC

Humidity

0~90%RH(no condensation)

Environmental pressure

86~106Kpa

Size

157*84.5*59.5mm (including back clip/water trap filter) (length * width * height)

Weight

365g (including battery, belt clip and filter)

Bluetooth function(Optional) Gas Concentration Meter O2 LEL H2S CO CO2 data can be transmitted to the mobile phone or PC in real time





TVOC Gas Analyzer Advantage:



Rugged and durable



1. The instrument can effectively resist a three-meter drop
2. The protection level of the instrument reaches IP67
3. The instrument has passed the EMC anti-static interference test and can work normally in the walkie-talkie environment



Explosion-proof circuit design, safe and reliable



The instrument has got IECEX, ATEX, explosion-proof certificates and the explosion-proof level reaches Exia IICT4 Ga



Multiple security protection



1. The man down alarm function has upgraded the safety of underground operators
2. Password protection function prevents non-operators from modifying menu parameters
3. With safety reminder function, sound and light vibration alarm function, let operators work without worries
4. The high and low alarm latched function allows the operator to better capture the sudden change of the gas concentratio value



Simultaneous measurement of multiple gases, multiple numerical display



1. The instrument can detect 1-5 gases at the same time
2. Real-time value, TWA, STEL, MAX, MIN multiple numerical display



Large screen display, flexible detection system, multiple filtering devices



1. The screen can be automatically turned 180 degrees, which is convenient for viewing in specia operating environments
2. Built-in powerful sampling pump, fast detection speed

3. Can be connected 20m sampling tube externally, which is convenient for long-distance or confined space detection
4. Pump suction and diffusion dual use, to provide operators with more reliable protection
5. With a water trap filter, it can effectively filter water, oil, dust and other impurities. It can also be used in harsh industrial environments such as coal mines and petroleum fields



Powerful function, more user-friendly operation



1. Beautiful and friendly user interface, reasonable and easy-to-use interactive mode

2. Optional Bluetooth function, data can be transmitted to the mobile phone or PC in real tim Standard storage function, one-click data export, convenient for users to analyze

3. Unique modifiable ID identification function, convenient for users to allocate and manage the instrument
4. A full range of automatic detection functions, automatic prompts for voltage, pump failure alarms, etc., more comfortable to use 5. One-key security detection
6. one-key open storage, automatic image flip
7. Support PPM and mg/m3 gas unit switch, the concentration value is automatically converted by the system Support each channel sensor to restore the factory setting separately
9. Support multi-language including English.Chinese and etc.


VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 0
VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 1
VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 2


IECEX ATEX CE Certifications:

VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 3

VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 4
VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 5





Factory Information



A Professional: We have been focused on gas detection devices for more than 10 years and been cooperating with PB group, PetroChina, Sinopec, Huawei, Samsung, Panasonic, etc famous companies. We are with rich experience to provide you professional solutions.

B Innovation: Strong R&D team (invest 40% revenues into research and experienced engineers team) makes our products stand out in the market.
C Quality: International top brands sensor and IC /100% production test, make sure a good quality.
D Professional technical support: Provide detailed pre-sales and after-sales technical support, no need to worry about any problem during usage.
E Completed certifications: ATEX / IECEX / SIL / CE / CNEX / ISO9001/, meet government standard as well guarantee your safety health.
F Services: We provide 24*7 hours service, if there have any question, Celia will reply you in 1 hours. Meanwhile, we can provide OEM services.
G Delivery: We can ship it out in 2-3 days. For some mass production and special customised gas analyzer, we can ship it out in 7 days.



VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 6VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 7

VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 8

VOC Gas Analyzer IP67 ATEX IECEX CE Certification PID VOC Meter Monitor Waterproof Explosion-Proof 9
