Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation

Basic Information
Place of Origin: China
Brand Name: Safegas
Certification: IECEX, ATEX, ISO9001, CE, CNEX, SIL
Model Number: SKY3000
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Aluminum Suitcase
Delivery Time: 1 working days
Payment Terms: Credit Card, T/T
Supply Ability: 1000 pieces/week
Detail Information
Detected Gas: PH3 Phosphine, Etc, Other Gases Are Customized Measure Range: 0-5, 0-10, 0-20, 0-50, 0-100, 0-200, 0-500, 0-1000, 0-2000, 0-3000PPM, Other Measure Ranges Are Customized
Sampling: Inner Suction Pump Alarm Model: Sound Light Vibration
Resolution: 0.001ppm, 0.01ppm, 0.1ppm, 1ppm, Other Resolutions Are According To Sensors. Sensors: Original Imported From UK
Wireless: (Optioanal)Bluetooth APP Protect Grade: IP67
Color: Black Certification: IECEX&ATEX, ISO9001, CE, SIL
High Light:

PH3 Phosphine Gas Detector

,

SKY3000 Phosphine Gas Detector

,

PH3 Phosphine Gas Monitor


Product Description

Phosphine Gas Detector Measure PH3 0 to 5ppm 20ppm 100ppm For Pest Control Fumigation



Phosphine Gas Detector is very necessary to detect the PH3 level to keep safety, especially in Grain warehouse, research institute or different Fumigation environments. This PH3 Phosphine Gas Meter is accurate and can be trusted for different applications. We always use PH3 Phosphine Gas Meter to test fumigation process with measure range 0-1000ppm, 0-2000ppm; to test residual after fumigation with range 0-20ppm, 0-100ppm, etc.

Aplication for Phosphine Gas Detector
Mainly used in fumigation, pest control, granary, laboratory, petroleum chemical industry,metallurgy, mining, fire, gas, environmental protection, electric power, communication, papermaking, printing and dyeing, food reserves, city water supply, sewage treatment, food, brewing, research, education, national defense and other places.


Phosphine Gas Detector Advantage:



Rugged and durable



1. The instrument can effectively resist a three-meter drop
2. The protection level of the instrument reaches IP67
3. The instrument has passed the EMC anti-static interference test and can work normally in the walkie-talkie environment



Explosion-proof circuit design, safe and reliable



The instrument has got IECEX, ATEX, explosion-proof certificates and the explosion-proof level reaches Exia IICT4 Ga



Multiple security protection



1. The man down alarm function has upgraded the safety of underground operators
2. Password protection function prevents non-operators from modifying menu parameters
3. With safety reminder function, sound and light vibration alarm function, let operators work without worries
4. The high and low alarm latched function allows the operator to better capture the sudden change of the gas concentratio value



Simultaneous measurement of multiple gases, multiple numerical display



1. The instrument can detect 1-5 gases at the same time
2. Real-time value, TWA, STEL, MAX, MIN multiple numerical display



Large screen display, flexible detection system, multiple filtering devices



1. The screen can be automatically turned 180 degrees, which is convenient for viewing in specia operating environments
2. Built-in powerful sampling pump, fast detection speed

3. Can be connected 20m sampling tube externally, which is convenient for long-distance or confined space detection
4. Pump suction and diffusion dual use, to provide operators with more reliable protection
5. With a water trap filter, it can effectively filter water, oil, dust and other impurities. It can also be used in harsh industrial environments such as coal mines and petroleum fields



Powerful function, more user-friendly operation



1. Beautiful and friendly user interface, reasonable and easy-to-use interactive mode

2. Optional Bluetooth function, data can be transmitted to the mobile phone or PC in real tim Standard storage function, one-click data export, convenient for users to analyze

3. Unique modifiable ID identification function, convenient for users to allocate and manage the instrument
4. A full range of automatic detection functions, automatic prompts for voltage, pump failure alarms, etc., more comfortable to use 5. One-key security detection
6. one-key open storage, automatic image flip
7. Support PPM and mg/m3 gas unit switch, the concentration value is automatically converted by the system Support each channel sensor to restore the factory setting separately
9. Support multi-language including English.Chinese and etc.



Accessories & Configuration List



Standard Accessories

SKY3000
Aluminum suitcase
A charging adapter
User Manual
Qualification/Calibration certificate

Filter

Storage function(USB cable)



Optional Accessories

Probe

Tube

Bluetooth App





Phosphine Gas Detector Specifications:

Sampling method

Pump suction

Gas type

Phosphine, PH3 etc, other gases are customized

Measure range

0-1ppm, 0-5ppm, 0-10ppm, 0-20ppm, 0-50ppm, 0-100ppm, 0-200ppm, 0-500ppm, 0-1000ppm, 0-2000ppm, 0-3000ppm, other measure ranges are customized

Resolution

0.001ppm, 0.01ppm, 0.1ppm, 1ppm, other resolutions are customized.

Response time

≤10 seconds

Precsiion

≤±1%F.S

Language

English(Other languages can be customized)

Automatically test and calibrate after power-on

Including reset, maximum value (MAX), minimum value (MIN), STEL, TWA value

Unit

PPM and mg/m³ can be switched

Disaply

monochrome graphics (160 x96) ,screen can be automatically flipped

Backlight

The backlight time can be manually set, and will be turned on automatically when an alarm is issued

Data record

Can store 100,000 sets data, the storage interval is adjustable from 5 to 3600 seconds, data can be exported

Alarm

95dB buzzer (@30cm), vibration alarm and flashing red LED and alarm status indication on the screen, alarm latched; diagnostic alarm and battery undervoltage alarm, pump block alarm; man down alarm, with early warning and optional real-time remote Bluetooth notification function

Battery

3.7V rechargeable lithium battery, battery capacity 2200mA

Working hours

More than 15 hours in continuous pumping mode

Charger

Travel charger with DC interface, charging time ≥ 4 hours

Explosion-proof grade

IECEX/ATEX(II IG Ex ia IIC T4
CNEX:Ex ia IIC T4 Ga

Certification
(EU regulations)

2004/108/EC(EMC)
1995/5/EC(Radio)
94/9/EC(ATEX)

Protection grade

IP67/IP68

Working temperature

-20ºC~+50ºC

Humidity

0~90%RH(no condensation)

Environmental pressure

86~106Kpa

Size

157*84.5*59.5mm (including back clip/water trap filter) (length * width * height)

Weight

365g (including battery, belt clip and filter)

Bluetooth function(Optional) Gas Concentration Meter O2 LEL H2S CO CO2 data can be transmitted to the mobile phone or PC in real time
Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 0
Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 1
Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 2


IECEX ATEX CE Certifications:

Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 3

Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 4
Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 5





Factory Information



A Professional: We have been focused on gas detection devices for more than 10 years and been cooperating with PB group, PetroChina, Sinopec, Huawei, Samsung, Panasonic, etc famous companies. We are with rich experience to provide you professional solutions.

B Innovation: Strong R&D team (invest 40% revenues into research and experienced engineers team) makes our products stand out in the market.
C Quality: International top brands sensor and IC /100% production test, make sure a good quality.
D Professional technical support: Provide detailed pre-sales and after-sales technical support, no need to worry about any problem during usage.
E Completed certifications: ATEX / IECEX / SIL / CE / CNEX / ISO9001/, meet government standard as well guarantee your safety health.
F Services: We provide 24*7 hours service, if there have any question, Celia will reply you in 1 hours. Meanwhile, we can provide OEM services.
G Delivery: We can ship it out in 2-3 days. For some mass production and special customised gas analyzer, we can ship it out in 7 days.



Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 6Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 7

Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 8

Phosphine Gas Detector Measure PH3 0 To 5ppm 20ppm 100ppm For Pest Control Fumigation 9





FAQ

Q1: Are you factory or trade company?
A1: We are a professional Phosphine Gas Detector manufacturer with 16 years experiences.


Q2: What about the payment method?
A2: Credit card, T/T, Western Union are available


Q3: Does your company accept customization?
A3: We do customizing service for customers.


Q4: What about the Shipment?
A4: We’ll choose proper transportation mode based on the weight of goods, usually arrange shipment byair express such as DHL,FEDEX,TNT or UPS.


Q5: What about after-sale service?
A5: 12 months warranty or 24 months warranty for Phosphine Gas Detector.



Q6: How about the Calibration?

A6: Before send out, we will calibrate Phosphine Gas Detector well with standard gas.



Q7: What certifications do you have?

A7: ATEX CE ISO9001-2015 for Phosphine Gas Detector.
