Basic 30%VOL CNEX Certified Flue Gas Analyzer For Domestic Gas Boiler

Basic Information
Place of Origin: China
Brand Name: Safegas
Certification: ATEX, ISO9001, CE, CNEX, SIL
Model Number: SKY2000-WH-M4
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: Aluminum Suitcase
Delivery Time: 1 working days
Payment Terms: Credit Card, Western Union, T/T
Supply Ability: 1000 pieces/week
Detail Information
Detected Gas: CO SO2 NOx O2 Measure Range: O2: 0-30%VOL, CO: 0-10000PPM, NOx: 0-2000PPM, SO2: 0-2000PPM
Sampling: Built In Pump Alarm: Sound And Light
Resolution: O2: 0.01%VOL, CO: 1PPM, NOx: 1PPM, SO2: 1PPM Package: Aluminum Suitcase
Sensor: Imported From UK/US Calibration: Yes, With Calibration Certification
High Light:

30%VOL Flue Gas Analyzer

,

CNEX Flue Gas Analyzer

,

Boiler Exhaust Gas Detector


Product Description



Cheapest Flue Gas Analyzer Basic Gas Analyzer Domestic Gas Boiler ATEX CE CO SO2 NOx O2



Boiler Flue Gas Analyzer Characteristics

1. Use original imported sensors from UK and US, brand is City and Honeywell.
2. Data transmission by USB cable, which can download and print data.
(Optional)
3. Gas type, unit, concentration and local time can be showed on the screen.
4. Support English
language.
5. The gas concentration unit PPM and mg/m3 can be shifted quickly.

6. Built-in sampling pump to make sure faster response

7. Explosion-proof certification, explosion-proof grade: II 2G Ex ia IIC T4 Ga IP66.

8. With Self-calibration and zero calibration functions
9. One press to restore factory setting, free from the bother of mis-operation.

10. With temperature and pressure compensation, this is able to realize gas concentration compensation under conditions of different temperatures or pressures.
11. Two-stage alarm with sound and light, alarm point is settable.
12. Special engineering plastics housing of high intensity, anti-skipping, water-proof, dust-proof, explosion-proof.



Boiler Flue Gas Analyzer specifications​



Gas Detected

CO SO2 NOx O2, gases can be customized.

Detection principle

Electrochemistry

Sampling Method

Pumping Suction

Measure Range

O2: 0-30%VOL, CO: 0-10000PPM, NOx: 0-2000PPM, SO2: 0-2000PPM, etc(ranges can be customized)

Resolution

O2: 0.01%VOL, CO: 1PPM, NOx: 1PPM, SO2: 1PPM

Precision

≤± 2-3% F.S

Signal Output

High-speed data transmission by USB, available for data downloading and
printing (optional function)

Charging Time

4~6h

Working Time

14h

Battery

3.7V

Capacity

2300mAh

Zero shift

≤±1%(F.S/year)

Display

LCD dot matrix display

Operating language

English

Gas unit

Units are switchable

Temperature

-20℃~50℃

Humidity

0-95%RH

Explosion-Proof

II 2G Ex ia IIC T4 Ga IP66

Degree of protection

IP66

Alarm mode

Sound, light, vibration

Housing Material

ABS+ leather case

Dimensions

131*83*35mm

Weight

240g







Basic 30%VOL CNEX Certified Flue Gas Analyzer For Domestic Gas Boiler 0



Accessories & Configuration List



Standard Accessories

SKY2000-WH-M4
Aluminum suitcase
A charging adapter
User Manual
Qualification/Calibration certificate



Optional Accessories

Probe

Tube

Filter

Storage function(USB cable + Software)



Basic 30%VOL CNEX Certified Flue Gas Analyzer For Domestic Gas Boiler 1



Application

Basic 30%VOL CNEX Certified Flue Gas Analyzer For Domestic Gas Boiler 2



Furniture, Floor, Wallpaper, Coating, Gardening, Interior Decoration and Renovation, Dyestuff, Papermaking, Pharmacy, Health Care, Foodstuff, Antiseptic.
Disinfection, Chemical Fertilizer, Resin, Adhesive, Pesticide, Raw Material, Sample, Technological Process,
Livestock Farm, Refuse Processing Plant, Perm Place.
Bio-pharmaceutical Plant, Green Household, Livestock Breeding, Green House Cultivating, Warehouse Logistics, Brewing And Fermentation, Agricultural Production.

Basic 30%VOL CNEX Certified Flue Gas Analyzer For Domestic Gas Boiler 3



Basic 30%VOL CNEX Certified Flue Gas Analyzer For Domestic Gas Boiler 4
