| Place of Origin: | China |
|---|---|
| Brand Name: | Yuante |
| Certification: | ATEX,CE |
| Model Number: | YT-1200H-S |
| Minimum Order Quantity: | 1 piece |
| Price: | Negotiable |
| Packaging Details: | Color box and carton |
| Delivery Time: | 3 working days |
| Payment Terms: | Western Union, T/T |
| Supply Ability: | 3000 pieces/month |
| Sensor Type: | Electrochemistry | Measure Range: | 0-100%LEL |
|---|---|---|---|
| Resolution: | 1%LEL | Model Number: | YT-1200HS-S |
| Application: | Power Plant, Petrochemical, Pharmaceutical, Building, Mine, Metallurgical Coking | Housing Material: | ABS+ Leather Case |
| Packaging Type: | Color Box And Carton | Country Of Original: | China |
| High Light: | Combustible Gas Leakage Detector,LEL Gas Leakage Detector,ATEX Certification Single Gas Detector |
||
Combustible Gas Leakage Detector EX LEL Detector With ATEX CE Certification
The YT-1200H series gas detector is a portable style with small size, low cost and high accuracy, which can measure the height of the instrument. Convenient and versatile, it can measure hazardous environments such as toxic gases, flammable gases and oxygen. The style of the back against the seam, protected by a silicone shell, suitable for different occasions.
This application customer needs to customize, single gas, gas, gas number more than set alarm moderate, can display up to a number of gas values, should wait for the measured gas exceeded or set the alarm appropriate time, the instrument will self-vibration alarm, sound, light, vibration alarm, can alarm. Widely used in power plants, petrochemical, pharmaceutical, construction, mining, metallurgical coking to prevent accidents. One is a flexibly configurable composite gas detection alarm.
Specification
| Gas Detected | EX gas detection device | ||
| Detection principle | Catalytic combustion | ||
| Sampling Method | diffusion | ||
| Measure Range | 0-100%LEL | ||
| Resolution | 1%LEL | ||
| Precision | ≤± 3% F.S. | ||
| Data recording |
Storage capacity of over one hundred thousand sets. Interval time ranges from 10-3600seconds are settable.(Optional function) |
||
| Response Time | ≤30S | Recovery Time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%(F.S/year) | Display | Monochrome dot matrix display |
| Operating language | Chinese/English | Gas unit | ppm, mg/m3,%VOL,%LEL |
| Temperature | -20℃~50℃ | Humidity | 0-95%RH |
| Explosion-Proof | ExiaⅡCT4 | Degree of protection | IP66 |
| Alarm mode | Sound, light, vibration | Operating time | 14 hour continuously |
| Dimensions | 131*83*35mm | Weight | 240g |
| Charger | Travel charger with USB | Charging time | 4-6 hours |
