| Place of Origin: | China |
|---|---|
| Brand Name: | SZYUANTE |
| Certification: | IECEX/ATEX/CE |
| Model Number: | YT-98H-A |
| Minimum Order Quantity: | 1 piece |
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | 3-5 working days |
| Payment Terms: | T/T, Western Union, Credit Card |
| Supply Ability: | 100 pieces/week |
| Model Number: | YT-98H-A | Detected Gas: | PH3 |
|---|---|---|---|
| Sensor Principle: | Electrochemical | Measure Range: | 0-10PPM, 0-2000PPM |
| Resolution: | 0.001PPM, 1PPM | Install Method: | Wall-mounted, Piping Type, Flow-type |
| Power Supply: | 24V DC | Gross Weight: | 5 KG |
| Product Size: | 286*202*96mm | Warranty: | 12 Month |
| High Light: | PH3 Toxic Gas Detector Monitor,24DV Toxic Gas Detector,High Temperature Probe Gas Leak Monitor |
||
PH3 Toxic Gas Detector Monitor With Optional High Temperature Probe
PH3 Toxic Gas Leak monitor 12-24DV with optional high temperature probe
Company profile
Our advantage
Product Overview
YT-98H-A series is a built-in pump-suction single & multi gas detector, which can detect 1-6 kinds of gases simultaneously and continously. With IECEx, ATEX certificate (on-going) and non-contact magnetic wand design, it can be installed and operated in explosion proof areas in Oil & Gas industry. In addition to 3-wire 4-20mA output with relay, it also offers Modbus protocols, making it compatible with most control systems. With optional wireless function, operator can view data on laptop, mobile phone or cloud system remotely.
Specification
| Gas detected | PH3 | ||
| Detection principle | Electrochemical | ||
| Install method | Wall-mounted, piping type, flow-type (according to the detected environment) | ||
| Measure range | 0-10PPM, 0-2000PPM | ||
| Resolution | 0.001PPM, 1ppm | ||
| Precision | ± 3% FS | ||
| Signal output | 4-20mA, 0-5V, RS485, relay(optional) | ||
| Response time | ≤10S | Recovery time | ≤10S |
| Repeatability | ≤±1% | Linearity error | ≤±1% |
| Zero shift | ≤±1%(FS/year) | Display |
2.4 inch color display, resolution 320*240
|
|
Wireless output (optional):
|
Wireless transmission function, provide SMS Alert, can upload data to the platforms, and transmit signals without distance limitation(optional)
|
Unit | ppm, mg/m³, %vol |
| Temperature | -20 to 50°C | Humidity | 0-95%RH |
| Explosion-proof | Ex dⅡCT6 | Degree of protection | IP65 |
| Alarm | Sound, light |
Language:
|
Chinese / English
|
| Dimensions |
(H x W x D) 320*210*110mm
|
Weight | ≤2kg |
Pictures from customer for Sensor PH3 RS485 MODBUS
FAQS
