Detail Information

Product Name:	Fixed Gas Detector	Measure Range:	Specified According To Application
Gas:	EX/LEL/CH4/O2/CO/H2S/CO2（optional)	Sensor Type:	Specified According To Application
Language:	Chinese/English	Alarm Type:	Light+Sound+Vibration
Detection Principle:	Pumping Electrochemical, NDIR, Catalytic, PID, Etc	Weight:	1KG
Size:	157.8x128.8x69.6mm	Power Dissipation:	Toxic Gas<2.5W,flammable Gas<4W
Communication Mode:	4-20mA(3-wires),RS485 1~5V,Hart(Optional)
Highlight:	0-500ppm Fixed Gas Detector , Hydrogen Nitrogen Fixed Gas Detector , Stainless Steel Fixed Gas Detector

Product Description

Product video

Safegas Stainless Steel Hydrogen Nitrogen Fixed Gas Detector IECEx ATEX Certified 0-1000ppm 0

Our advantages

Safegas Stainless Steel Hydrogen Nitrogen Fixed Gas Detector IECEx ATEX Certified 0-1000ppm 1

Product description

Safegas Stainless Steel Hydrogen Nitrogen Fixed Gas Detector IECEx ATEX Certified 0-1000ppm 4

Safegas Stainless Steel Hydrogen Nitrogen Fixed Gas Detector IECEx ATEX Certified 0-1000ppm 5

SG100 series is a cost-effective gas detector for continuous monitoring of toxic gases, oxygen,flammable, VOC gases.It is IECEx, ATEX certified,with intrinsically safe explosion grade. Havinga 2 wireor 3 wire4 to 20 mA analog output, RS485 modbus output, optional HART output, making it to be compatible with most control systems. With optional wireless data transmission, customer is able to review, download thedata remotely. Support both magnetic andremote control,flexibleforsetting.

Product advantage

IP66/IP68 water & dust resistant
Intelligent plug and play sensor module. the module support calibration by Safegas PC software, making replacement and maintenance easier.
With standard splash guard to protect sensor for
outdoor installation or environment with water splash.
Small and light, weight is only 1 kg,and the detector
comes with standard mounting bracket, easy for installation
Standard 4-20 mAanalogsignal output andRS485

modbus signal output, optionalHart output, 2 wire output.

Compatible with most of control systems.
The detector comes with 3 relays, including low/high/fault

alarm relay(Optional)

Safegas Stainless Steel Hydrogen Nitrogen Fixed Gas Detector IECEx ATEX Certified 0-1000ppm 7

company profile

Safegas Stainless Steel Hydrogen Nitrogen Fixed Gas Detector IECEx ATEX Certified 0-1000ppm 12

certifications

FAQ

specification

Gas type	Specified according to application
Sensor type	Specified according to application
Accuracy	≤±2-5%FS (Depending on the specific sensor)
Measure Range	Specified according to application
Resolution	Specified according to application
Display:	LED display
Explosion-proof grade	IECEX:Ex db IIC T6 Gb,Ex db ia IIC T6 Gb ； ATEX:Ex db IIC T6 Gb,Ex db ia IIC T6 Gb
Protection grade	IP66/68
Power dissipation	Toxic gas<2.5W,flammable gas<4W
Communication mode	4-20mA(3-wires),RS485 1～5V,Hart(Optional)
Working voltage	12-24VDC
Size	157.8x128.8x69.6mm
Weight	LORA, 4G(Optional)
Wireless	≤±1%

Tag:

Place of Origin:	China
Brand Name:	safegas
Certification:	ATEX/IECEX
Model Number:	SG100-xs

Minimum Order Quantity:	1 piece
Price:	310USD
Delivery Time:	3-5days
Payment Terms:	T/T
Supply Ability:	8000 pcs per month
