Detail Information

Product Name:	Fixed Gas Detector	Measure Range:	Specified According To Application
Gas:	EX/LEL/CH4/O2/CO/H2S/CO2（optional)	Sensor Type:	Specified According To Application
Language:	Chinese/English	Alarm Type:	Light+Sound+Vibration
Detection Principle:	Pumping Electrochemical, NDIR, Catalytic, PID, Etc	Weight:	1KG
Size:	157.8x128.8x69.6mm	Power Dissipation:	Toxic Gas<2.5W,flammable Gas<4W
Communication Mode:	4-20mA(3-wires),RS485 1~5V,Hart(Optional)
Highlight:	6 In 1 Fixed Gas Detector , ATEX Stainless Steel Detector , Wholesale Stainless Steel Detector

Product Description

Product video

Safegas Wholesale Stainless Steel Detector 6 In 1 Fixed Gas Detector Alarm Function IECEx ATEX Certified 0-1000ppm 0

Our advantages

Safegas Wholesale Stainless Steel Detector 6 In 1 Fixed Gas Detector Alarm Function IECEx ATEX Certified 0-1000ppm 1

Product description

Safegas Wholesale Stainless Steel Detector 6 In 1 Fixed Gas Detector Alarm Function IECEx ATEX Certified 0-1000ppm 4

Safegas Wholesale Stainless Steel Detector 6 In 1 Fixed Gas Detector Alarm Function IECEx ATEX Certified 0-1000ppm 5

SG100 series is a cost-effective gas detector for continuous monitoring of toxic gases, oxygen,flammable, VOC gases.It is IECEx, ATEX certified,with intrinsically safe explosion grade. Havinga 2 wireor 3 wire4 to 20 mA analog output, RS485 modbus output, optional HART output, making it to be compatible with most control systems. With optional wireless data transmission, customer is able to review, download thedata remotely. Support both magnetic andremote control,flexibleforsetting.

Product advantage

IP66/IP68 water & dust resistant
Intelligent plug and play sensor module. the module support calibration by Safegas PC software, making replacement and maintenance easier.
With standard splash guard to protect sensor for
outdoor installation or environment with water splash.
Small and light, weight is only 1 kg,and the detector
comes with standard mounting bracket, easy for installation
Standard 4-20 mAanalogsignal output andRS485

modbus signal output, optionalHart output, 2 wire output.

Compatible with most of control systems.
The detector comes with 3 relays, including low/high/fault

alarm relay(Optional)

Safegas Wholesale Stainless Steel Detector 6 In 1 Fixed Gas Detector Alarm Function IECEx ATEX Certified 0-1000ppm 7

company profile

Established in 2010, Shenzhen Yuante Technology Co., Limited has been engaged in the gas detection business for 16 years. We focus on creating advanced gas detection equipment and systems, with gas detectors as our flagship products. Our solutions are tailored to industries like Energy, Environmental Protection, and Electronic, ensuring safety and efficiency.

In the past 10 years of rapid growth, we have emerged as an influential supplier. We adhere to the principles of market orientation, innovation-driven, quality-based survival, and development-oriented growth. Our corporate culture and management system have cultivated a team of professionals, including a proficient R & D team.

Our detectors are renowned for their accuracy and quick response. By combining years of experience with innovative R & D and international learning, our products outperform domestic brands and are competitive globally. We are dedicated to meeting the evolving demands of our customers.

Safegas Wholesale Stainless Steel Detector 6 In 1 Fixed Gas Detector Alarm Function IECEx ATEX Certified 0-1000ppm 12

certifications

FAQ

specification

Gas type	Specified according to application
Sensor type	Specified according to application
Accuracy	≤±2-5%FS (Depending on the specific sensor)
Measure Range	Specified according to application
Resolution	Specified according to application
Display:	LED display
Explosion-proof grade	IECEX:Ex db IIC T6 Gb,Ex db ia IIC T6 Gb ； ATEX:Ex db IIC T6 Gb,Ex db ia IIC T6 Gb
Protection grade	IP66/68
Power dissipation	Toxic gas<2.5W,flammable gas<4W
Communication mode	4-20mA(3-wires),RS485 1～5V,Hart(Optional)
Working voltage	12-24VDC
Size	157.8x128.8x69.6mm
Weight	LORA, 4G(Optional)
Wireless	≤±1%

Tag:

Place of Origin:	China
Brand Name:	safegas
Certification:	ATEX/IECEX
Model Number:	SG100-xs

Minimum Order Quantity:	1 piece
Price:	310USD
Delivery Time:	3-5days
Payment Terms:	T/T
Supply Ability:	8000 pcs per month
