Detail Information

Product Name:	Fixed Gas Detector	Measure Range:	0-100%LEL
Gas:	CH4	Sensor Type:	Specified According To Application
Language:	Chinese/English	Alarm Type:	Light+Sound+Vibration
Detection Principle:	Pumping Electrochemical, NDIR, Catalytic, PID, Etc	Weight:	1KG
Size:	157.8x128.8x69.6mm	Power Dissipation:	Toxic Gas<2.5W,flammable Gas<4W
Communication Mode:	4-20mA(3-wires),RS485 1~5V,Hart(Optional)
Highlight:	Fixed Flue Gas Detector , 316 Stainless Steel So2 Gas Detector , High Precision So2 Gas Detector

Product Description

Product video

Fixed Flue Gas Detector Imported Sensor High Precision Alarm Function 316 Stainless Steel So2 Gas Detector For Industrial Use 0

Our advantages

Fixed Flue Gas Detector Imported Sensor High Precision Alarm Function 316 Stainless Steel So2 Gas Detector For Industrial Use 1

Product description

Fixed Flue Gas Detector Imported Sensor High Precision Alarm Function 316 Stainless Steel So2 Gas Detector For Industrial Use 4

Fixed Flue Gas Detector Imported Sensor High Precision Alarm Function 316 Stainless Steel So2 Gas Detector For Industrial Use 5

The SG100 series gas detector is a remarkable device designed to meet the demanding requirements of continuous gas monitoring. It is specifically engineered to detect a wide range of gases, including toxic gases, oxygen, flammable substances, and VOC gases, with high precision and reliability. This detector holds the prestigious IECEx and ATEX certifications, ensuring its safety and compliance in hazardous environments. The intrinsically safe explosion grade further enhances its suitability for use in potentially explosive atmospheres.

Featuring a 2-wire or 3-wire 4 to 20 mA analog output, along with RS485 modbus output and an optional HART output, the SG100 series offers seamless integration with most control systems, facilitating efficient data transfer and management. The optional wireless data transmission capability allows customers to remotely review and download data, providing real-time insights and enhancing operational flexibility. Additionally, the support for both magnetic and remote control enables easy and flexible device settings, making it convenient for users to customize the detector according to their specific needs. With its advanced features and cost-effective design, the SG100 series is a top choice for industries where gas detection is crucial.

Product advantage

IP66/IP68 water & dust resistant
Intelligent plug and play sensor module. the module support calibration by Safegas PC software, making replacement and maintenance easier.
With standard splash guard to protect sensor for
outdoor installation or environment with water splash.
Small and light, weight is only 1 kg,and the detector
comes with standard mounting bracket, easy for installation
Standard 4-20 mAanalogsignal output andRS485

modbus signal output, optionalHart output, 2 wire output.

Compatible with most of control systems.
The detector comes with 3 relays, including low/high/fault

alarm relay(Optional)

Fixed Flue Gas Detector Imported Sensor High Precision Alarm Function 316 Stainless Steel So2 Gas Detector For Industrial Use 7

company profile

Fixed Flue Gas Detector Imported Sensor High Precision Alarm Function 316 Stainless Steel So2 Gas Detector For Industrial Use 12

certifications

FAQ

specification

Gas type	flammable gases(CH4)
Detection Principle:	Electrochemical, NDIR, Catalytic, PID, etc
Accuracy	≤±2-5%FS (Depending on the specific sensor)
Measure Range	Specified according to application
Resolution	Specified according to application
Display:	LED display
Explosion-proof grade	IECEX:Ex db IIC T6 Gb,Ex db ia IIC T6 Gb ； ATEX:Ex db IIC T6 Gb,Ex db ia IIC T6 Gb
Protection grade	IP66/68
Power dissipation	Toxic gas<2.5W,flammable gas<4W
Communication mode	4-20mA(3-wires),RS485 1～5V,Hart(Optional)
Working voltage	12-24VDC
Size	157.8x128.8x69.6mm
Weight	LORA, 4G(Optional)
Wireless	≤±1%

Tag:

Place of Origin:	China
Brand Name:	safegas
Certification:	ATEX/IECEX
Model Number:	SG100-xs

Minimum Order Quantity:	1 piece
Price:	310USD
Delivery Time:	3-5days
Payment Terms:	T/T
Supply Ability:	8000 pcs per month
