High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response

High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response
High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response
High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response
Basic Information
Place of Origin: China
Brand Name: safegas
Certification: CE/ISO
Model Number: YT-95H
Minimum Order Quantity: 1 piece
Price: 1010USD
Delivery Time: 3-5days
Payment Terms: T/T
Supply Ability: 8000 pcs per month
Get Best Price Contact Now
Detail Information
Product Name: Fixed Gas Detector Measure Range: Specified According To Application
Gas: CO/H2S/Customized Sensor Type: Specified According To Application
Language: Chinese/English Alarm Type: Light+Sound+Vibration
Detection Principle: Electrochemical, NDIR, Catalytic, PID, Etc Weight: ≤1.6kg
Size: 180×150×90mm Power: 12-36V DC
Communication Mode: G1/2 External Thread Explosion-proof Flexible Pipe Thread Size: M45*2mm
Temperature: –20℃～50℃ Humidity: 0-95%RH(nocondensation)
Explosionproof Grade: Ex D IIC T6 Gb
Highlight:

High Precision Fixed Gas Detector

,

C3H8O Gas Detector

,

Fast Response Fixed Gas Detector

Product Description

Product video


High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 0




Our advantages

High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 1

Product description

YT-95H/YT-95H-A series detectors are efficient in industrial gas monitoring. They can precisely detect various gases. Customizable measurement range and high - resolution detection make them suitable for different industrial needs.



These detectors have useful functions. Online monitoring with real - time data display and optional alarms work 24/7. The infrared remote control enables remote operations. Their diverse output signals integrate well with control systems. Wireless data transmission options enhance data accessibility.



The die - cast aluminum housing with IP65 protection can withstand harsh environments. With short response time, high repeatability, and low zero drift, they ensure stable operation. Their high explosion - proof grade makes them ideal for dangerous industrial settings.

High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 2High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 3High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 4High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 5High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 6


Product advantage
  • Online monitoring with sound/light alarm(Optional)

24h continuously monitoring, data will real-time display.High/low alarm with sound and light, sound >90dB, alarm point is settable.

  • Convenient remote control
With infrared ray controller, which can remote control alarm point settings, zero calibration, and address modification.
  • Diversified output signals

 ​​It integrate 3 wire 4-20 mA analog, RS485 Modbus and relay out. To be compatible with different control systems.

  • Relay control

The relay output supports control external devices such as horns, alarm lights, fans etc.

  • ​Data transmission to PC
Through PC software can remote monitor the data.Wireless data transmission including Lora, 4G (Optional)
  • Durable housing

​​Die-cast aluminum housing, strong and durable;IP65 protection degree,water-proof, dust-proof,explosion-proof；
High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 7High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 8High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 9


company profile

In 2010, Shenzhen Yuante Technology Co., Limited was born with a dream of revolutionizing the gas detection field. In the early days of entrepreneurship, the team, with their dedication to technology and sharp market insights, kept exploring. From overcoming one technical problem after another to collaborating with various industries, they gradually built a complete industrial chain. Today, Yuante Technology has won market recognition with high - quality products and services. This is just the starting point of its great journey, and more exciting stories will be created in the future.

High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 10High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 11High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 12High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 13High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 14High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 15High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 16

certifications

High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 17

FAQ

High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 18High Precision Fixed C3H8O Gas Detector 0-100% LEL with Imported Sensor And Fast Response 19

specification

Gas type Specified according to application
Sensor type Specified according to application
Accuracy
≤±2%FS(Specified according to different sensor)
Measure Range Specified according to application
Resolution Specified according to application
Display:
4 digits Nixie tube display.
Explosion-proof
grade
Ex d IIC T6 Gb
Temperature
–20℃～50℃
Power
12-36V DC
Thread Size
M45*2mm
Zero shift
≤±1%(F.S./year)
Dimensions
180×150×90mm
Weight
≤1.6kg
Humidity

0-95%RH(nocondensation)
