Name: Portable Ozone Gas Detector with IP66/68 Protection 0.01ppm Resolution, and Electrochemical Principle for Industrial Safety
Brand: Shenzhen YuanTe Technology Co., Ltd. (Safegas)
SKU: Minimeta
Price: 1,037.00 USD
Availability: InStock

Detail Information

Principle:	Electrochemical Principle	Working Temperature:	-20℃ To 55℃
Display:	Gas Name, Battery Power, Concentration Unit, Measured Value	Response Time(T90):	15 To 30s
Working Humidity (non-condensing):	0-95%RH	Resolution:	0.01ppm
Working Air Pressure:	86 To 106kpa	Alarm Mode:	Sound, Light, Vibration Alarm
Weight (With Clip):	125g	Dimensions:	90mm60mm33mm (lengthwidththickness)
Measure Range:	0-20PPM	Detection Principle:	Diffusion
Accuracy:	≤±2-5%FS	Gas Detected:	O3
Power Supply Mode::	3.6V Dry Battery (non-rechargeable And Replaceable)	Alarm Type:	Low Alarm, High Alarm, STEL, TWA, Low Battery Optional Calibration Due And Bump Test Due
Explosion-proof Certification:	IECEx, ATEX	Protection Class:	IP66/68
Highlight:	IP66/68 Protection Ozone Gas Detector , 0.01ppm Resolution Portable Gas Monitor , Electrochemical Principle Single Gas Detector

Product Description

Ozone O3 Gas Detector Personal Wearable Gas Monitor For Industrial Safety

Minimeta Portable O3 Gas Detector

High-precision portable gas detector for O3 detection with diffusion detection principle, designed for industrial safety applications.

Product Overview

MiniMeta is an IECEX/ATEX/EMC certified single-gas detector. It can detect hundreds of user-selected toxic gases, user friendly and easy for operation. The battery and sensor is replaceable to provide user a long-term protection. It is designed to offer a low cost and long-term ownership gas monitoring system.

Key Features

IP68 water- and dust-resistant case
Low power consumption with 2 years standby time, no need battery charge and calibration
With Single /multi unit docking station to perform daily bump test and calibration (Optional)
With event and data logging function
With self-test function, which can improve safety by automatic self-test
Small size, lightweight and with back clip for easily carry
95db@30cm buzzer alarm, 2 high-bright red LED light alarm and vibration alarm
Real time value, TWA, STEL, MAX, MIN multiple numerical display

Technical Parameters

Detect gas	O3
Sensor type	Electrochemical
Sampling method	Diffusion
Measure range	0-20PPM
Resolution	0.01ppm
Precision	≤± 3% F.S.
Response Time	≤30s(T90)
Unit	PPM
Display	Gas name, concentration unit, measured value, electricity
Alarm mode	Sound, light, vibration alarm, high and low alarm values can be set by yourself
Alarm type	Low alarm, high alarm, STEL, TWA, low battery
Display	LCD Display
Operating language	Chinese/English
Size	906033mm
Weight	125g
Working Temperature	-20ºC~50ºC
Working Humidity	0-95%RH
Working air pressure	86~106kpa

Company Advantages

R&D team experience: over 25 years
Company certifications: ISO9001, ISO45001
Product certifications: IECEx, ATEX, CE
Delivery time: 5-7 days
Annual capacity: 80,000 units
Professional 7*24 hours customer service

Manufacturer Profile

Established in 2010, Shenzhen Yuan Te Technology Co., Limited (Safegas) specializes in the design, production, and sales of gas detection equipment and systems. With 16 years of industry experience, we provide comprehensive solutions for various sectors including Oil, Chemical, Medicine, Energy, Environmental Protection, Electronics, Municipal Engineering, Agriculture, and Household Appliances.

Product Line

Our product portfolio includes portable detectors, fixed systems, controller panels and particle counter:

Portable: Minimeta, Micmeta, YT-1200H-S, SKY3000, SKY2000, SKY8000, SKY1000, MAXMETA
Fixed: YT-95H, YT-98H, YT-96H, SG100, SG200
Controllers: YT-1100H, YT-1600H, YT-1800H
Particle Counter: AQD5000, SKY6000-PM, SKY2000-PM
