| Place of Origin: | China |
|---|---|
| Brand Name: | Safegas |
| Certification: | ATEX, CNEX, ISO9001, CE |
| Model Number: | YT-1200H-S-VOC |
| Minimum Order Quantity: | 1pcs |
| Price: | Negotiable |
| Packaging Details: | Color paper box |
| Delivery Time: | 2-3 working days |
| Payment Terms: | Credit Card, Western Union, T/T |
| Supply Ability: | 1000 pieces/week |
| Detected Gas: | VOC, TVOC, VOCs, TVOCs | Measure Range: | 0-1ppm, 0-3ppm, 0-10ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-10000ppm |
|---|---|---|---|
| Ampling Method: | Diffusion | Alarm Type: | Sound, Light, Vibration |
| Resolution: | 0.001ppm, 0.01ppm, 0.1ppm, 1ppm | Packing: | Color Paper Box |
| Material: | PC + ABS | USB Port: | Mini USB Port |
| High Light: | Mini VOC Gas Detector,Diffusion Type VOC Gas Detector,Back Clip VOC Gas Analyzer |
||
Mini Size VOC Gas Detector Volatile Organic Compounds Gas Analyzer Diffusion Type With Back Clip
VOC Sensor Monitoring advantage:
Specifications
| Gas Detected | VOC, TVOC, VOCs, TVOCs | ||
| Detection principle | Electrochemisty | ||
| Sampling Method | Diffusion | ||
| Measure Range | 0-1ppm, 0-3ppm, 0-10ppm, 0-100ppm, 0-500ppm, 0-1000ppm, 0-10000ppm | ||
| Resolution | 0.001ppm, 0.01ppm, 0.1ppm, 1ppm | ||
| Precision | ≤± 3% F.S. | ||
| Signal Output | High-speed data transmission by USB, available for data downloading and printing (optional function) |
||
| Charging Time |
4~6h |
Working Time | 14h |
|
Battery |
3.7V |
Capacity |
2300mAh |
| Zero shift | ≤±1%(F.S/year) | Display | LCD dot matrix display |
| Operating language | Chinese/English | Gas unit | Units are switchable |
| Temperature | -20℃~50℃ | Humidity | 0-95%RH |
| Explosion-Proof | II 2G Ex ia IIC T4 Ga IP66 | Degree of protection | IP66 |
| Alarm mode | Sound, light, vibration |
Housing Material |
ABS+ leather case |
| Dimensions | 131*83*35mm | Weight |
240g |
Pictures
Characteristics
Employ original imported high-precision sensor.
Four random gas sensors can be combined freely.
LCD dot matrix display, support Chinese and English operation.
The gas concentration unit PPM and mg/m3 can be shifted quickly.
The battery and voltage can be checked by one press.
One press to restore factory settings.
Ultra-high buzzer alarm sound, alarm with sound, light and vibration at the same time.
Can record 100 sets alarm data, alarm record can be checked on the device.
Data storage function, can record 100 thousand set data, historical data can be viewed on the device (optional function).
Rechargeable lithium polymer battery of large capacity, which ensure the device to work
continuously for a long time.
Strong and upscale alligator clip, convenient to take along during operation.
Special engineering plastics housing of high intensity, strong and durable, exquisite and comfortable in touching.
FAQ
Q1: Are you factory or trade company?
A1: We are factory.
Q2: What about the payment method?
A2: T/T, Western Union are available
Q3: Does your company accept customization?
A3: We do customizing service for customers.
Q4: What about the Shipment?
A4: We’ll choose proper transportation mode based on the weight of goods, usually arrange shipment byair express such as DHL,FEDEX,TNT or UPS.
Q5: What about after-sale service?
A5: 12 months warranty or 24 months warranty for all kinds of products.
