Name: IECEX Certified Multi Gas Detector with IP66/IP68 Protection and Lightweight 240g Design for Industrial Safety
Brand: Shenzhen YuanTe Technology Co., Ltd. (Safegas)
SKU: Micmeta
Price: 2,210.00 USD
Availability: InStock

Detail Information

Gas Type:	Can Be Customized, Up To 5 Gases	Working Method:	Diffusion Sampling
Response Time(T90):	Less Than 30 Seconds	Calibration Platform:	Optional Docking Station To Perform Daily Calibration And Bump Test
Battery:	3.7V Lithium Battery, Rechargeable	Wireless Transmission:	Optional Bluetooth Or Lora Wireless Transmit
Working Hours:	24 Hours	Charging Time:	Less Than 6 Hours
Certification:	ATEX, CN, IECEX	Protection Grade:	IP66/IP68
Weight(with Internal Battery):	240g	Data Record:	1000 Sets
Events Record:	100 Sets
Highlight:	IP68 Multi Gas Detector , Back Clip Multi Gas Detector , IP66 Multi Gas Detector

Product Description

IECEX Certified Multi Gas Detector with IP66/IP68 Protection Grade and Back Clip

Product Overview

Safegas Portable Multi Gas Detector Light Weight IECEX certificated IP68 drop resistant Diffusion Suction With Back Clip

MicMeta is a multi-gas detector with IP66/IP68 protection. Under normal circumstances, Micmeta can detect 1-4 gases simultaneously. With two conventional range gases (CO and H2S), it can detect up to 5 gases at the same time.

Micmeta has obtained three explosion-proof certifications: IECEX, ATEX, and China Explosion-proof. The explosion-proof level is Ex ia IICT4 Ga/Ex ia I Ma, allowing use in both Zone 0 and Zone 1 simultaneously.

Micmeta features an LCD screen with Chinese/English language switching support and gas unit conversion. It includes two-level sound and light alarms with customizable alarm points, optional PC software for data download, and optional docking station for bump testing, calibration, configuration, and data recording.

Product Images

Product Advantages

Compact and Lightweight: Small size with light weight (240g), robust and durable construction withstands drops up to 1.5 meters. IP66/IP68 rating provides effective waterproof and dustproof protection.
User-Friendly Operation: Simple two-button operation for easier use.
Bright Visual Alarm: Features a wide-angle visual alarm bar for increased visibility.
EMC Tested: Successfully passed EMC anti-static interference tests, ensuring reliable operation in various environments.
Ergonomic Design: Includes a comfortable, wear-resistant back clip that is lightweight for easy carrying.

Product Specifications

Sampling method	Diffusion suction
Gas type	Can be customized, detect up to 5 gases
Measure range	Customized
Resolution	Customized
Response time	≤60S (T90)
Precision	≤±5%FS or ±10% (depends on the specific sensor)
Language	Chinese/English
Automatically test and calibrate after power-on	Including auto-test, calibration, auto-zero, maximum value (MAX), minimum value (MIN), STEL, TWA value
Unit	PPM and mg/m³ can be switched and displayed by one key, concentration value automatically converted by system
Display	Segment code LCD display
Calibration platform	Modification, function testing and calibration operations can be performed on DKM-MicMeta docking station (optional)
Data record	1000 sets data records and 100 sets events records
Alarm	95dB buzzer (@30cm), vibration alarm and flashing red bar, on-screen alarm status indication, alarm lock; Diagnostic alarms and battery undervoltage alarms, man down alarms, all sensor alarm value is settable
Battery	3.7V rechargeable lithium battery, battery capacity 2300mA
Working hours	Standby time 18h, charging time <6h
Wireless transmission	Bluetooth transmission function (optional), Lora transmission function (optional)
Explosion-proof grade	IECEx: Ex ia IIC T4 Ga, Ex ia I Ma ATEX: II 1G Ex ia IIC T4 Ga, Ex ia I Ma (EU regulations): 2004/108/EC(EMC), 94/9/EC(ATEX), CE
Protection grade	IP66/IP68
Working temperature	-20°C~55°C
Humidity	0-95%RH (non-condensing)
Environmental pressure	86～106Kpa
Size	1136032mm (length * width * height)
Weight	200g (with lithium battery)

Detectable Gases

Micmeta can detect 1-5 gases simultaneously. Here are some of the gases Micmeta can detect:

Applications

Chemical Industry

Environmental Monitoring

Healthcare Applications

Automotive Industry

Industrial Safety

Wastewater Treatment

Greenhouse Gas Monitoring

Oil and Gas Exploration

Food and Beverage Production

Mining and Mining Operations

Why Choose Us?

R&D team experience: Over 25 years
Company certification: ISO9001, ISO45001
Product certification: IECEx (the only one in China), ATEX, CE
Delivery: 5-7 days
Yearly capacity: 80,000 units
Service: Professional sales staff provide 7*24 hours service

Company Profile

Established in 2010, Shenzhen Yuan Te Technology Co., Limited (Safegas) is a company that focuses on the design, production and sales of gas detection equipment and systems for 16 years. With "gas detector" as the core product, we have completed production lines and solutions for different industries including Oil, Chemical, Medicine, Energy, Environmental Protection, Electronic, Municipal Engineering, Agriculture and Forestry, and Household Appliances.

Product Line

Our products include portable types, fixed types and controller panels:

Portable types: Minimeta, Micmeta, YT-1200H-S, SKY3000, SKY2000, SKY8000

Fixed types: YT-95H, YT-98H, YT-96H, SG100, SG200

Controller panels: YT-1100H, YT-1600H

Certifications

IECEX, ATEX, CE, TEST Report, ISO 9001, ISO 45001

Companies We Cooperated With

Huawei, Coca-Cola, Samsung, Nestlé and more.

Safegas corporate partners including Huawei, Coca-Cola, Samsung, Nestlé

Frequently Asked Questions

Q1: What is a gas detector?

A1: A gas detector is an instrument for gas leakage concentration detection, including portable gas detectors and fixed gas detectors.

Q2: What does a gas detector detect?

A2: Combustible gases: Natural gas (methane), liquefied gas, coal gas, acetylene, pentane, alkynes, toluene, etc.
Toxic gases: Carbon monoxide, hydrogen sulfide, ammonia, chlorine, phosphine, sulfur dioxide, hydrogen chloride, chlorine dioxide and other toxic and harmful gases.

Q3: What is the ppm unit of the gas detector?

A3: ppm represents the volume concentration of the gas, meaning the volume of pollutants contained in one million volumes of air. For example, if the concentration of ammonia is 30ppm, it means that the volume of ammonia in one million volumes of air is 30.
