| Gas Detected: | Argon(Ar) | Measure Range: | 0-100%VOL |
|---|---|---|---|
| Detection Principle: | Thermal Conductance | Resolution: | 0.1%VOL |
| Sampling Method: | Pump Suction (Pump Can Be Turn Off) | Alarm Mode: | Alarm By Sound, LED And Vibration |
| Protection Grade: | IP66 | Operating Time(with Pump Off): | 100 Hours |
| Weight: | 300g | Temperature: | From -20℃ To 50℃ |
| Humidity: | Within 0 To 90%RH | ||
| Highlight: | Imported Sensor Argon Gas Detector,Quick Response Argon Gas Detector,Pump Suction Argon Gas Detector |
||
| Gas Detected | Argon (Ar) |
|---|---|
| Measure Range | 0-100%VOL |
| Detection Principle | Thermal Conductance |
| Instrument Lifespan | Sensors: 2-3 years, Instruments: ≥5 years |
| Linearity Error | ±2%FS |
| Response Time | T90<30S (25℃) |
| Sampling Method | Pumping Suction |
| Resolution | 0.1%VOL |
| Signal Output | Optional USB for data transmission |
| Operating Language | Chinese/English |
| Temperature Range | -20℃~50℃ |
| Explosion-Proof | Ex ia II CT4 |
| Alarm Mode | Sound, Light, Vibration |
| Dimensions | 205×75×32mm |
| Recovery Time | ≤10S |
| Display | LCD Dot Matrix |
| Gas Unit | Switchable Units |
| Humidity | 0-90%RH |
| Protection Level | IP66 |
| Operating Time | 100h (pump off) |
| Weight | 300g |
