Measure Range: | Specified According To Application | Gas: | EX/LEL/CH4/O2/CO/H2S/CO2(optional) |
---|---|---|---|
Sensor Type: | Electrochemical, Catalytic Combustion | Language: | Chinese/English |
Alarm Type: | Light+Sound+Vibration | Sampling: | Suction |
Working Environment: | -40 ℃ ~ 70 ℃, <95% RH (no Dew) | Weight: | 300g |
Size: | 205*75*32mm | ||
Highlight: | Imported Sensor Multi Gas Detector,Remote Monitoring Platform Multi Gas Detector,IECEx Certification Multi Gas Detector |
Product advantage
1.Original imported first- class brand sensor.
2.(Optional)High speed data transmission by USB, which can download and print data.
3.LCD dot matrix display, the gas type, unit, concentration.
4.Local time can be showed on the screen.
5.Support Chinese and English operation, easy to shift.
6.The gas concentration unit PPM and mg/m³ can be shift quickly.
7.Built-in micro sampling pump, 10 grades of suction are available.
8.Explosion-proof certification, explosion-proof frade:Exia IIC t4 Ga..
Established in 2010, Shenzhen Yuante Technology Co., Limited is a company that focuses on the design, production and sales of high-end gas detection equipment and system for 16 years.With gas detector as the core product, we have completed production line and solutions according to different industries,
Gas type | Specified according to application |
Sensor type | Specified according to application |
Sampling Method | Suction |
Measure Range | Specified according to application |
Resolution | Specified according to application |
Precision | ≤± 3% F.S. |
Signal Output | High-speed data transmission by USB, available for data downloading and printing(optional) |
Response Time | ≤10S |
Display: | LCD Display |
Zero shift | ≤±1%(F.S/year) |
Operating language | Chinese/English |
Size | 205*75*32mm |
Weight | 300g |
Repeatability |
≤±1% |
