High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design

Basic Information
Place of Origin: China
Brand Name: safegas
Certification: ATEX/IECEX
Model Number: SKY3000
Minimum Order Quantity: 1 piece
Price: 1710USD
Delivery Time: 3-5days
Payment Terms: T/T
Supply Ability: 8000 pcs per month
Detail Information
Product Name: Portable Gas Detector Measure Range: Specified According To Application
Gas: EX/LEL/CH4/O2/CO/H2S/CO2(optional) Sensor Type: Specified According To Application
Language: Chinese/English Alarm Type: Light+Sound+Vibration
Detection Principle: Pumping Electrochemical, NDIR, Catalytic, PID, Etc Weight: 365g (including Battery, Belt Clip And Filter)
Size: 157*84.5*59.5mm (including Back Clip/water Trap Filter) (length * Width * Height) Sampling: Pump Suction
Display: Monochrome Graphics (160 X96) ,screen Can Be Automatically Flipped
Highlight:

High Precision Portable Multigas EO Detector

,

IP67 Certified Portable Multigas EO Detector

,

PID Sensor Portable Multigas EO Detector


Product Description

Product video


High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 0




Our advantages

High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 1

Product description

High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 2High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 3

High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 4High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 5High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 6High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 7

SKY3000 is a IECEX/ATEX/EMC certified portable multigas detector. It is suction type with built-in pump to detect up to 6 gas types in 1 device. The standard gas type is multi 4 (CO H2S O2 LEL) gases. There are thousands of gas types for selection to support very wide applications.It’s with wireless communication so user can access to real-time data and alarm status remotely. The standard data log function to export data to PC and no need software.



Product advantage

  • IP67 water & dust resistant and 3 meter drop resistant case, rugged and durable designs
  • Standard man down alarm function
  • Real time value, TWA, STEL, MAX, MIN multiple numerical display
  • One press to restore factory settings.
  • Large graphical display can rotate 180°
  • Standard water trap filter to protect the sensor
  • With docking station to perform daily bump test and calibration (Optional)Wireless data transmission including Lora, Bluetooth (Optional)
  • Support backlight function the backlight time can be manually set
  • Low power consumption, long stand by time
  • Support firmware upgrade remotely





High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 8High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 9

company profile



Since its establishment in 2010, Shenzhen Yuante Technology Co., Limited has been committed to gas detection for 16 years. Our success is built on the strength of our team. We design, produce, and sell high - quality gas detection equipment and systems, with gas detectors as our main products. Our industry - specific solutions for Municipal Engineering and Agriculture and Forestry are the result of our team's collective efforts.
After a decade of development, we've made a mark in the market. Our management concept, which values the market, innovation, quality, and development, has created a corporate culture that nurtures talent. Our management and R & D team, with their diverse skills and experiences, are the backbone of our company.
The essence of our detectors lies in their accuracy and rapid response. Through independent R & D, cooperation, and learning from overseas, our team has developed products that outshine domestic counterparts and are approaching global standards. We believe in the power of teamwork to drive our company forward.


High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 10High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 11High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 12High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 13High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 14High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 15High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 16

certifications

High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 17

FAQ

High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 18High Precision Portable Multigas EO Detector With PID Sensor 0-10ppm IP67 Certified And Rugged Design 19

specification

Gas type Specified according to application
Sensor type Specified according to application
Sampling Method Pump suction
Measure Range Specified according to application
Resolution Specified according to application
Response time(T90):
≤10 seconds
Automatically test
and calibrate after
power-on
Including reset, maximum value (MAX), minimum value (MIN), STEL, TWA value
Display:
monochrome graphics (160 x96) ,screen can be automatically flipped
Data Record:
Can store 100,000 sets data, the storage interval is adjustable from 5 to 3600 seconds, data can be exported
Battery:
3.7V rechargeable lithium battery, battery capacity 2200mA
Working hours: More than 15 hours in continuous pumping mode
Size 157*84.5*59.5mm (including back clip/water trap filter) (length * width * height)
Weight 365g (including battery, belt clip and filter)
Protection grade:

IP67/IP68
