Lightweight Diffusion Ozone Gas Detector

With Sound+Light+Vibration Alarm, IP65

A mini-size, low-cost, high-accuracy portable diffusion gas detector for ozone (O₃) monitoring. Measures from 0–50ppm with 0.1ppm resolution using an electrochemical sensor. Features LCD dot matrix display, sound, light & vibration alarm, 100 event logs (standard), optional 100,000 data logging, and a 2500mAh rechargeable battery for up to 14 hours continuous operation. Explosion-proof Ex ia IIC T4, IP65 rated. Ideal for water treatment, food processing, and industrial hygiene.

The YT-1200H-S series is a mini-size, lightweight portable multi-gas detector designed for hazardous environments. Using diffusion sampling, it requires no pump, making it simple and maintenance-free. The detector is housed in a strong, durable ABS + leather case with an alligator clip and protective silicone cover, suitable for various workplace conditions.

Taking ozone (O₃) as an example, the instrument uses an electrochemical sensor to measure concentrations from 0–50ppm with a resolution of 0.1ppm. It provides triple alarm (sound, light, vibration) with an ultra-high buzzer, and features a monochrome dot matrix LCD (128×128) with adjustable backlight that automatically turns on during alarm.

The detector comes standard with 100 event records (viewable on device) and supports optional data logging of up to 100,000 readings with adjustable interval (10–3600 seconds). Data can be exported to a PC via supplied software. One-key factory reset simplifies restoration.

Powered by a 3.7V 2500mAh rechargeable lithium battery, it operates continuously for 14 hours (with 4-gas combination) or up to 200 hours (without LEL sensor). Charging time is 4–6 hours.

• Mini size & lightweight – Easy to wear with back clip and silicone case protection.
• Triple alarm – Ultra-high buzzer + flashing LED + vibration alarm.
• LCD dot matrix display – 128×128 monochrome graphic LCD with adjustable backlight.
• Standard event logging – 100 event records can be viewed directly on the device.
• Optional data logging – Up to 100,000 readings; interval 10–3600 seconds; export to PC via software.
• One-key factory reset – Quick restoration to default settings.
• Large capacity battery – 2500mAh rechargeable lithium battery.
• Long operating time – 14 hours (4 gases) or 200 hours (without LEL sensor).
• Explosion-proof certified – Ex ia IIC T4 (suitable for Zone 1 and Zone 2 hazardous areas).
• IP65 protection – Dust-tight and protected against water jets.
• Easy to operate – Simple interface with comprehensive functions.

Ozone is a pale blue gas with a pungent odor. It is used for water disinfection, air purification, food processing, and industrial bleaching. However, ozone is a strong oxidizer and can be harmful to human health at elevated concentrations. Short-term exposure may cause throat irritation, coughing, and reduced lung function. The YT-1200H-S helps monitor O₃ levels to ensure safety in workplaces where ozone is generated or used.

• Water & wastewater treatment plants – Ozone disinfection byproduct monitoring.
• Food & beverage processing – Ozone sanitation in bottling, cold storage, and surface cleaning.
• Pharmaceutical manufacturing – Cleanroom and sterilization area monitoring.
• Indoor air quality – Offices, public buildings with ozone-generating equipment.
• Industrial hygiene – Worker exposure monitoring in printing, bleaching, and chemical industries.
• Laboratories – Fume hood verification and research areas.

Shenzhen YuanTe Technology Co., Ltd. (brand: Safegas) was established in 2010 and specializes in the R&D, manufacturing, and sales of gas detection equipment and integrated systems. With over 16 years of industry expertise, the company serves sectors including oil & gas, chemicals, environmental protection, electronics, municipal engineering, agriculture, and household appliances. All products are manufactured under ISO9001 and ISO45001 management systems, holding international certifications such as IECEx, ATEX, and EMC. With an annual production capacity of over 80,000 units, YuanTe Technology supplies gas detection solutions to customers worldwide.

• Established since 2010 – Over 16 years of experience in gas detection R&D and manufacturing.
• Full product range – Portable detectors, fixed transmitters, analyzers, control panels, and accessories.
• International certifications – IECEx, ATEX, EMC certified for hazardous areas (including coal mines).
• Wide gas & industry coverage – Hundreds of gases, serving oil & gas, chemical, mining, environmental, food, pharma, and more.
• Strong R&D & quality – ISO9001 & ISO45001 certified, with a professional R&D team and global service network.
• High production capacity – Over 80,000 units per year with fast delivery (5–7 working days typical).
• Global customer support – 24/7 after-sales service and solutions tailored to diverse industries.

YT-1200H-S O3 General FAQ

Q1: What gas does this detector monitor?

A: It monitors Ozone (O3).

Q2: What are the measuring range and resolution?

A: Range 0–50 ppm, resolution 0.1 ppm.

Q3: What is the detection principle?

A: Electrochemical sensor + diffusion sampling.

Q4: Does it support data recording?

A: Optional data logging for 100,000 readings; standard 100 event logs.

Q5: What alarm modes are available?

A: Sound + light + vibration triple alarm.

Q6: How long can it work continuously?

A: Up to 200 hours for O3 singlegas mode.

Q7: Is it explosion-proof?

A: Yes, Ex ia ⅡC T4 explosion-proof certified.

Q8: What is the protection level?

A: IP65 dustproof and splash-proof.

Q9: Can I export data to a computer?

A: Yes, via dedicated software.

Q10: What is the weight and size?

A: 240 g, dimensions 131×83×35 mm.
