Name: Field-Ready Laser Dust Monitor with 0–1000 µg/m³ PM2.5/PM10 Detection and Data Logging
Brand: Shenzhen YuanTe Technology Co., Ltd. (Safegas)
SKU: SKY8000
Price: 2,210.00 USD
Availability: InStock

Detail Information

Color:	Black And Green	Working Humidity:	≤95%RH, No Condensation
Wireless Transmit:	Optional, By 4G, LORA, WIFI	Display Type:	LCD With Backlight
Language:	Chinese/English	Sampling Type:	Built-in Pump Sampling
Accuracy:	≦±5% F.S.	Power Output:	DC 24V, 0.25A/channel
Response Time:	≤30 Seconds (T90)	Repeatability:	≤±1%
Single Gross Weight:	1.64kg	Precision:	≤±2%F.S Except For Special Gases
Work Temperature:	-40~70 Degree	Test Gas:	PM2.5/PM10
Highlight:	laser dust monitor PM2.5/PM10 , field-ready dust monitor data logging , 0–1000 µg/m³ dust monitor

Product Description

Field-Ready Laser Dust Monitor — SKY8000 Overview

The SKY8000 is a professional portable analyzer that combines real-time particulate monitoring with multi-gas detection in a single field-ready instrument. Engineered for environments where airborne dust and chemical hazards coexist, it delivers reliable particle data without compromising gas measurement capability. Whether for regulatory compliance, worker safety, or environmental research, the SKY8000 simplifies complex air quality assessments.

Why Measure PM2.5 and PM10?

Particle	Diameter	Common Sources
PM10	≤10 µm	Road dust, construction, agriculture, industrial emissions, pollen, mould spores
PM2.5	≤2.5 µm	Combustion (vehicle exhaust, power plants, wildfires), smoke, industrial processes, secondary aerosols

Health Effects

Short-term: Eye, nose, and throat irritation, coughing, shortness of breath, asthma flare-ups
Long-term: Reduced lung function, chronic bronchitis, cardiovascular disease, lung cancer, premature death
High-risk groups: Children, elderly, and people with heart or lung conditions

Where Professionals Use the SKY8000

Application Area	Examples
Ambient air monitoring	Urban, suburban, and industrial zones — compliance with WHO/EPA standards
Indoor air quality	Offices, schools, hospitals, hotels, homes
Construction & demolition	Fugitive dust control, regulatory compliance
Mining & quarrying	Worker exposure to respirable dust (silica, coal)
Woodworking & furniture	Wood dust monitoring, fire and health protection
Food processing	Flour, spice, and sugar dust — explosion and safety hazards
Pharmaceutical cleanrooms	Particle count validation (ISO 14644)
Wildfire & emergency response	Smoke plume monitoring, public health advisories
HVAC performance	Filter efficiency testing

Product Images

Key Technical Specifications

Detected parameters	PM2.5, PM10
Principle	Laser scattering
Range	0 – 1000 µg/m³
Resolution	1 µg/m³
Compatible gases	Up to 18 simultaneously (CO, H₂S, NO, NO₂, SO₂, VOC, etc.)
Sensor types	Electrochemical, catalytic, PID, semiconductor, infrared, laser (PM)
Precision	≤ ±2% FS (higher precision on request)
Pump flow rate	0 – 500 cc/min (adjustable)
Display	3.5-inch HD LCD, 320 × 480 resolution
Data storage	8G SD card (standard), custom logging intervals
Data interfaces	USB, RS485; optional LoRa, Bluetooth, 4G, WiFi
Printing	Optional built-in thermal printer or external Bluetooth printer
Battery (standard version)	10000mAh / 3.7V Li-ion
Battery (printer version)	5400mAh / 11.1V Li-ion
Run time	>32h (single gas) / >24h (six gases)
Charging port	Mini-USB (5V/2A standard; 13V/2A printer version)
Operating temperature	-40°C to +70°C (optional probe up to 1100°C)
Humidity	0–95% RH (non-condensing)
Protection class	IP65
Dimensions (H × W × D)	260 × 230 × 120 mm
Weight	3700 g

Key Features

Laser particle sensor — Real-time PM2.5/PM10 measurement with 1 µg/m³ resolution and 0–1000 µg/m³ range
Multi-parameter capability — Up to 18 gases plus dust in one portable unit
Built-in pump — Active sampling (0–500 cc/min, adjustable) ensures consistent intake
Multi-layer filtration — Protects sensors from oil, moisture, dust, and other impurities
Large colour display — 3.5-inch HD screen with switchable curve or numeric views
Ample data logging — 8G SD card stores years of data; recording intervals customisable
Flexible export & remote options — USB, RS485; optional LoRa, Bluetooth, 4G, WiFi for IoT integration
On-site printing — Optional built-in thermal printer for text, graphics, barcodes, or curves
High-temperature probe (optional) — Measures flue gas up to 1100°C
Long runtime — >24 hours with six gases active; >32 hours for single gas
Rugged construction — IP65 rated, aviation-grade wear-resistant materials, aluminium carrying case included

About the Manufacturer

Shenzhen YuanTe Technology Co., Ltd. (Safegas) — founded in 2010. With over 16 years of experience in R&D, manufacturing, and sales of gas detection and air quality instruments, the company offers a product range that includes portable detectors, fixed transmitters, gas analyzers, control panels, and calibration accessories. It serves the oil & gas, chemical, environmental, electronics, municipal, agriculture, and household appliance sectors.

Key Facts

Certified under ISO9001, ISO45001, IECEx, ATEX, EMC
Annual capacity: >80,000 units
Typical delivery: 5–7 working days
24/7 customer support

Frequently Asked Questions

Q1: What detection principle is used for PM2.5/PM10?

A1: Laser scattering principle — high accuracy and fast response.

Q2: What is the measuring range and resolution?

A2: Range 0–1000 µg/m³; resolution 1 µg/m³.

Q3: Does it have a built-in sampling pump?

A3: Yes, a built-in pump enables active sampling for more stable and accurate results.

Q4: Can it store measurement data?

A4: Yes, a standard 8G SD card supports interval recording and data export.

Q5: Does it support an alarm function?

A5: Yes, buzzer, LED, and screen alarms trigger when limits are exceeded.

Q6: Is it explosion-proof?

A6: Yes, Ex ic IIC T3 Gc — safe for industrial hazardous areas.

Q7: What is the working time?

A7: Up to 24 hours with six gases active.

Q8: Can I print data on site?

A8: Yes, an optional built-in printer is available.

Q9: What environments is it suitable for?

A9: Construction sites, mines, factories, urban air, industrial emissions, cleanrooms, and similar environments.

Q10: Does it support wireless remote monitoring?

A10: Yes, optional Bluetooth, WiFi, LoRa, or 4G modules allow remote viewing on mobile or PC.
